Chainline (approximate as BB centering and cranksets vary) - 48mm on 3x cranksets and 49mm on 2x
Compatibility
- These rings fit any 104 BCD crankset
- Designed to meet the requirements for E-bike use
- Chainring bolts:
- 104 x 32T - use
- 104 x 34T, 36T use , unless using a Bash ring
- Wolf Tooth’s patented wide/narrow tooth profile for the ultimate chain retention and mud shedding ability
- For 1x9, 1x10, 1x11 and 1x12 drivetrains (including SRAM Eagle)
- If using a 9-speed drivetrain use a 10-speed chain (shifts and works well on a 9-speed drivetrain and fits the ring tighter for better chain retention)
- Quarq power meter compatible with sizes 34t and 36t. Filing is required for 32t fitment onto some older Quarq Power meters. No modifications are required for the DUB Quarq Power meter.
- Threaded to use M8 chainring bolts (no nuts required)
- Ovality of 10% and timing of 112° after TDC (top dead center)
- Maximum diameter is that of a chainring 2t bigger than the size you order (so be sure there is adequate chainstay clearance.)
Recommendations
- If you plan to ride in very muddy conditions, we recommend a chainguide or chainkeeper in addition to a clutch-type rear derailleur. Without these precautions, you may experience chaindrops and/or chainsuck.
- Recommend the use of a clutch style rear derailleur for the best chain security.
Related Products
- If you need a ring smaller than 32t (smallest that fits on a 104 BCD), checkout out our that will mount to your "small ring" position.
Tech Specs
Weight: 32T • 41g | 34T • 48g | 36T • 55g (check elliptical 64 BCD rings for smaller sizes)
Material: 7075-T6 aluminum
Made in the USA
